Victron range of small Lithium batteries for small off grid set-ups that want to use Lithium batteries.  Ideal for light weight solutions.  70% small and 70% lighter than Lead acid batteries.

For multiple batteries it is imperative that you purchase the BMS, Battery Management System, to go with these batteries.  You will kill them quickly if you don’t use one.  We have the BMS here.

Lithium-iron-phosphate (LiFePO4 or LFP) is the safest of the mainstream li-ion battery types. The nominal voltage of a LFP cell is 3,2V (lead-acid: 2V/cell). A 12,8V LFP battery therefore consists of 4 cells connected in series; and a 25,6V battery consists of 8 cells connected in series.

These batteries have integrated Cell Balancing, Temperature and Voltage control (BTV). Up to ten batteries can be paralleled and up to four batteries can be series connected (BTV’s are simply daisy-chained) so that a 48V battery bank of up to 2000Ah can be assembled.  The daisy-chained BTV’s must be connected to a Victron battery management system (BMS).

Download full spec sheet here

The new style MultiPlus is set to replace the earlier MultiPlus Compact range. It is a powerful true sine wave inverter, a sophisticated battery charger that features adaptive charge technology and a high-speed AC transfer switch in a single compact enclosure.

Proven reliability The full bridge plus toroidal transformer topology has proven its reliability over many years. The inverter is short circuit proof and protected against overheating, whether due to overload or high ambient temperature.

PowerControl - Dealing with limited generator, shore side or grid power With the Multi Control Panel a maximum generator or shore current can be set. The MultiPlus will then take account of other AC loads and use whatever is extra for charging, thus preventing the generator or shore supply from being overloaded.

PowerAssist - Boosting the capacity of shore or generator power Where peak power is so often required only for a limited period, the MultiPlus will make sure that insufficient shore or generator power is immediately compensated for by power from the battery. When the load reduces, the spare power is used to recharge the battery. High start-up power Needed to start high inrush loads such as power converters for LED lamps, halogen lamps or electric tools.

Search Mode When Search Mode is ‘on’, the power consumption of the inverter in no-load operation is decreased by approx. 70%. In this mode the Multi, when operating in inverter mode, is switched off in case of no load or very low load, and switches on every two seconds for a short period. If the output current exceeds a set level, the inverter will continue to operate. If not, the inverter will shut down again.

Programmable relay By default, the programmable relay is set as an alarm relay, i.e. the relay will de-energise in the event of an alarm or a pre-alarm (inverter almost too hot, ripple on the input almost too high, battery voltage almost too low.

This is a really unique panel, at just over 1m x 1.5m, the perfect size to cap off a boat storage locker or small road trailer

Please check out the my solar camping trailer in the additional images.

FOR LARGE PANEL DELIVERY TIMES, SCHEDULES AND COSTS - CLICK HERE

• Listing is for one panel, just add the required number of panels to your basket.

54 CELL DELTA 295W MONOCRYSTALLINE SOLAR MODULE

The Triple Black DELTΔ SERIES 54 cell module from Perlight has proven extremely popular in the UK due to its sleek looks and diminutive size.

It is completely black with black busbars, a black back sheet and a black frame, which when installed in arrays, offers a more uniform appearance, enabling PV modules to integrate into new and existing buildings without necessarily making the array the focal point.

Not just aesthetically pleasing, the 295W Delta Black Monocrystalline module has PERC technology which essentially enables to improve light capture near the rear surface and to optimize electrons capture.

This module continues the trend from Perlight of well made, good looking products that offer outstanding value for money.

• 12 years product warranty
• 25 years performance warranty
• Ideal for small roofs

Victron Smart Solar 45A MPPT with max VOC 150V - with barewire terminals (contact us for MC4 terminals) 12 / 24 / 48V battery system voltage

MPPT: Ultra Fast Maximum Power Point Tracking

By constantly monitoring the voltage and current output of your solar (PV) panels, MPPT technology ensures that every drop of available power is rinsed out of your panels, and harvested for storage. The advantage of this is most noticeable when the sky is partially clouded, and light intensity is constantly changing.

Remote Monitoring and Control

Remotely control and monitor the extensive features of your SmartSolar MPPT charger with built-in bluetooth by pairing it with your smartphone or other device via VictronConnect. If your installation is connected to the internet Victron Remote Management Portal (VRM) provides access to the full power of your MPPT, anytime, anywhere; both services are free to use. For remote installations - even when there is no internet connection or phone signal nearby - you may be able to monitor your MPPT by bluetooth-pairing with a LoRaWAN(long-range wide area network) device, available optionally.

Optional SmartSolar Control Display

By adding the SmartSolar Control Display you will be able to check the status of your Charger and battery-storage at a glance. Simply plug it into the face of your MPPT charger to provide you with real-time monitoring and set-up capabilities.

VictronConnect

VictronConnect lets you get live status information and configure any Victron products which either have Bluetooth built-in, or are connected to a VE.Direct Bluetooth Smart Dongle.

Smart BMS 12/200

The Smart BMS 12/200 is an all-in-one Battery Management system for Victron Lithium-Iron-Phosphate (LiFePO4) Smart Batteries. It has been specifically designed for 12V systems with a 12V alternator such as in vehicles and boats.

It combines a Current Limiter, Battery Combiner and Battery Protector in a robust and compact solution and lets you safely connect any size 12V alternator (and starter battery), loads and chargers to Smart Lithium batteries.

The Smart BMS 12/200 monitors and protects each individual battery cell within the battery (or battery bank) and will disconnect the alternator, charge sources or DC loads in case of low battery cell voltage, high battery cell voltage or over temperature.

The dedicated alternator connection provides current limiting and one-way traffic from the alternator into the battery, this so any size alternator (and starter battery) can be safely connected to the Smart Lithium battery (or battery bank) and the starter battery is protected from excessive discharge.

The BMS is equipped with Bluetooth for monitoring and configuration, a remote on/off connector, to turn the BMS (and the system) off via a remote switch and a pre-alarm contact, to give a warning signal before the BMS will disconnect the batteries from the system.

The BMS is also equipped with a remote on off connector, to turn the BMS (and the system) off via a remote switch.

The Lynx Distributor contains a positive and a negative busbar. The positive busbar has four fuse-protected connections with fuse monitoring. The negative busbar has four connections and a ground connection. It is part of the Lynx Distribution system and is available in two versions, with M8 or M10 busbar. Note that M10 refers to the busbar connection joints where the modules are connected to each other. The fuse and cable connections are always M8. The Lynx Distributor has a power LED and four fuse status indication LEDs. If connected to a Lynx Smart BMS, up to 4 Lynx Distributors can send fuse status information to the Lynx Smart BMS. This feature is not available when connected to a Lynx Shunt VE.Can.

*This listing is for the M8 version.*

It will monitor the status of each fuse and indicate its condition with a LED if used in conjunction with Lynx Shunt VE Can. The Lynx Distributor is part of the modular Lynx distribution system. See here for the Lynx Power In bus bar https://www.bimblesolar.com/Victron-lynx-powerin

The Digital Multi Control is used to remotely view and adjust AC input currents, and turn on and off the Multi or Quattro. It is designed to integrate cleanly with your boat, vehicle or house system control panel.

The Digital Multi Control panel (DMC) is designed to work with all Multi/Quattro. This includes stand alone, parallel and 2-3 phase configurations. Connecting the DMC to your system is simple, in most cases just connecting the DMC with an RJ45 cable is sufficient and no extra set-up handling is required.

The Smart Battery Shunt

The SmartShunt is an all in one battery monitor, only without a display. Your phone acts as the display. The SmartShunt connects via Bluetooth to the VictronConnect App on your phone (or tablet) and you can conveniently read out all monitored battery parameters, like state of charge, time to go, historical information and much more.

Alternatively the SmartShunt can be connected and be read by a GX device. Connection to the SmartShunt is made via a VE.Direct cable.

The SmartShunt is a good alternative for a BMV battery monitor, especially for systems where battery monitoring is needed but less wiring and clutter is wanted.
The SmartShunt is equipped with Bluetooth, a VE.Direct port and a connection that can be used for: monitoring a second battery, midpoint monitoring or a temperature sensor.

This unit has M10 bolts.

Power inlet for boat (shore power inlet), van, living vehicle or motorhome.

16A. 250VAC

Solid Cast 316 Stainless Steel

Brass, Nickel plated pins

IP56 rating

This would require a hole making in the vehicle/vessel exterior as it is panel mounted (recessed)

300A Battery isolator switch, 900A for 30 secs, up to 48 Volt, M10 connection. Can be use on 12, 24 or 48 Volt system as long as switch current rating is not exceeded.

BLUE SEA M-SERIES SELECTOR SWITCHES

M-SERIES BATTERY SWITCHES

300 Ampere continuous rating.

• Tin-plated copper studs for maximum conductivity and corrosion resistance
• Studs accept 3⁄8" (M10) ring terminals
• 7⁄8" (22mm) stud length accepts multiple cable terminals
• One-piece terminal stud design never loosens over time
• Case design allows surface or rear panel mounting options
• Label with international legends
• Tactile indicator conveys knob position by feel

Regulatory

• CE marked, ISO 8846
• UL Listed - UL 1107 electric power switches
• Meets ABYC requirements
• Meets UL1500 and SAE J1171 external ignition protection requirements
• IP66 protects against powerful water jets

Fixes without screwing holes in your roof!

Panels over 175w should be bolted down, these are unsuitable.

Set of seven black solar panel mounting kit, including 6 brackets (4 corners and 2 sides) and cable gland.

They are ideal for fixing our solar panels to any vehicle, caravan, boat, barge or even outbuildings and sheds to provide a strong, secure and aesthetically pleasing fixing method, the mounts will support the solar panel at the correct height above the surface to enable the flow of air underneath the panel and keep it cool, ensuring the solar panel functions at it's optimum.

The mounts can be safely bonded to the surface removing the need to drill holes.  The panel is secured by screwing or bolting it to the mounting corner, but the corner itself can be fixed with a good strong adhesive like 'Sikaflex' or 'CT1' or any polyurethane sealant to the roof. (Ensure the roof is clean and dry before attaching.   If a painted roof ensure the paint is not flakey)

ABS mounts raise the panel by 25mm.  Edge of panel to edge of ABS is 55mm.

We sell CT1 which is great for sticking these down, please see related products tab for different colours avaialble.

If you are fitting to a vehicle we recommend that you additionally bolt or screw the panel and mounting down as well, as the strength of these systems is only as strong as the roof type or paint on your roof!

NOTE - You need to purchase additional self tappers or bolts to fit the panel to the ABS mounts, see below for one method...

Here is a good tutorial to get you started:

ABS Mounting tutorial

Victron MK3-USB Configuration Interface

The MK3-USB allows the following products to connect to a computer for configuration and firmware updates using the Victron VE Configure software

Multi, MultiGrid, MultiPlus, MultiPlus-II, Quattro, Inverter/Charger settings in ECOmulti, EasySolar, EasyPlus, and other Inverters with a VE.Bus communication port.

Counsider purchasing a Cat 5 ethernet cable to go with this product if you don't already have one. You won't be able to connect the MK3 interface to an inverter product without an ethernet cable.

Supported Platforms

The VEConfigure tools are only available for Windows. For Mac, there is a (not officially supported) work around available.

35mm² cable per meter, Class 6 multi-stranded extra flexible tinned copper conductor, 225A rated for 5mins @ 100% Duty cycle

Conductor diameter 6.7mm, Overall diameter including sheath 13mm

Kraus & Naimer DC Switch

Switch - Disconnectors, 2 pole - for single string

•            IP66/67 Protection

•            Black/Grey Padlockable Handle – lockable in the OFF-position

•            Class II compliant, Grey Insulated Enclosure

•            Switch Interlocked with lid to prevent opening in “ON” position

•            Rated for use in ambient temperatures of 50°C

Plastic Enclosures, Protection IP66/67, totally insulated, M20/M25 knock-outs
Handle black, Plate Backing grey
Contact development: 2 pole, 6 contacts per circuit (2 x 3 in series)
Dimensions (w x h x d): 100mm x 178mm X 93mm

For use with our stick down panels and ABS mounting kits - also great for sealing cable holes

CT1 will successfully bond:

• Metals (including lead)
• Glass
• Mirrors
• Wood
• Polystyrene

Unique adhesion on virtually any material in most applications without the need for additional fixings. CT1 is the ultimate solution for sealing.
Excellent resistance to chemicals

• Prevents fungal growth
• UV resistant
• Excellent resistance to vibration
• Food safe - conforms to ISEGA Standards
• Works in wet or dry conditions
• Perfect for marine and boating maintenance, accident and emergency repairs
• Can be used in all salt-water environments
• Odourless
• Does not shrink
• Can be painted
• Contains no solvents
• No isocyanates
• Unique flexibility
• Environmentally compliant
• Instant repair and bonding with fibre glass and carbon fibre materials

Application
Apply with a standard cartridge caulking gun or pneumatic version at approximately 6 bar (108psi)

Drying Time
Skin cure 23ºC 50% R.H. 8 minutes
Non-adhering 23ºC 50% R. 25minutes
Full cure time 23ºC 50% R.H. 24hrs - 6mm (48hrs - 7/12mm)

Premade 6mm Solar Cable with Male to Female MC4 connectors, quick and easy to install.

(Please note if using as a cable run from panel to controller, you would cut in half giving you 2 x 5m lengths, MC4 to bare wire.)

Double Insulated UV protected solar cable

Max load: 70A in air

Our solar cable is ozone resistant according to BS EN 50396

UV resistant according to HD 605 S2 and is tested for durability according to EN 60216

Flexible tinned copper conductor

Conductor
Class 5 flexible tinned copper conductor
Insulation
Halogen-free cross-linked compound
Sheath
Halogen-free cross-linked, flame retardant compound
Sheath Colour
Black

Fitted with Staubli 4-6mm MC4s - Staubli MC4 Link

Wire size range: 6mm2

VE.Direct non inverting remote on/off cable

Use this cable to remotely control BlueSolar and SmartSolar MPPT charge controller models.

Note that it's not necessary to use this cable on the larger SmartSolar models, as they feature an onboard Remote On/Off terminal.

The charger will be enabled when the signal on the cable is high. The charger is disabled when the source signal is pulled low or left free floating.

Note that when using this cable, it's not possible to use the VE.Direct port for any other purpose. Such as connecting to a GX device, or for example a VE.Direct Bluetooth Smart dongle on a BlueSolar charger.

200A Fuse for 12v or 24 systems - Pack of 5 fuses

For use with Mega Fuse Holder

60A Fuse for 12v or 24 systems - Pack of 5 fuses

For use with Mega Fuse Holder

Premium Enhanced Cat5e UTP Patch Cables

Communications cable for use with equipment that requires ethernet RJ45 cables. This model is 3 metres long, blue in colour and the connections are booted - partially covered as per image.

• Connectors: 50 micron gold RJ45 plugs
• Cable: UL approved Cat.5 Enhanced 24AWG stranded cable
• To reduce crosstalk, short bodied connectors maintain speed & data integrity
• Moulded design suitable for advanced and new build networks

Protect your off-grid or grid tied PV system from unexpected string faults using Mersen’s HelioProtection® fuse line

Developed specifically for the protection of PV string wiring for 1000VDC industrial rooftop and utility scale photovoltaic systems. Its robust construction makes it ideal for continuous temperature and current cycling withstand adding to system longevity. The 1000VDC rated fuse is designed for low minimum breaking capacity capabilities of 1.35 times the fuse rated current value, allows for safe circuit interruption under typical low fault current conditions produced by PV arrays.

The 10 X 38mm fuse can be used standalone with the DIN mount string fuse holder to fuse a single circuit or as a bank of fuses in a solar combiner box.

This item fits String Fuse holder

One pole DIN rail mount fuse holder for 10 X 38 type fuses, suitable for protecting and isolating solar panel strings between the array and the charge controller input for example.

Rated to 1000VDC, 32A, accepts up to 16mm² cable. For use stand alone or for incorporation into a PV combiner Box with the 13 way bus bar and feeder terminal to take off  the supply to a solar charge controller or solar inverter.

Choose fuse separately

Item dimensions 75mm H X 16mm W X 55mm D

35mm squared cable end lug for crimping onto 35mm² multi-stranded battery cable. Heavy duty lug with flared cable entry. Tin plated copper. Made in the UK

35mm squared cable end lug for crimping onto 35mm² multi-stranded battery cable. Heavy duty lug with flared cable entry. Tin plated copper. Made in the UK

16mm squared cable end lug for crimping onto 16mm² multi-stranded battery cable. Heavy duty lug with flared cable entry. Tin plated copper. Made in the UK

Ideally 6mm solar cable max - for bigger units with bigger cable click here

Unit best used for housing 1 x AC RCBos, string fuse holders and fuses up to 32a as opposed to DC Din Mount breakers.

Best practice would be to use this unit with no bigger than 6mm square cable and appropriately sized breakers if you are using it with glands for a water tight fit.  If you are using it in an environment that is already dry and dust free the use of glands may not be necessary.

This is an empty unit, you must add the breakers you need to your cart as well, see related items tab above to see the breakers that fit.

You will also need suitable cable entry glands - please see related products tab.
