Victron MultiPlus-II 48/4k5/55-32 230V

Brand: Victron Energy

Price: £499.17 +vat
£599 (including VAT)
Only 2 left in stock

Pay Monthly Finance - Apply Now

Availability: In Stock - Delivery 1-3 days or collect from near Lewes

SKU: PMP482405012

Victron Price Match, Pre-Programming, Pre-Made Boards & Extended Warranty:

We can price match or beat any supplier, do get in touch.
Pre-Programming, we can program your system to save you time & money.
Pre-made Boards, we offer mounted and wired van electrical boards also custom pre-built off grid electrical boards to any size.
Extended Victron Warranty is available 10% surcharge 5 years to 10 years.
Contact us 01273 931110 or [email protected] for any of the above.

ID: 4033

Victron Specifications
Battery Voltage Nominal	48 V
Power Control	1
Power Assist	1
Parallel Operation	1
Three Phase Operation	1
Number Ac Inputs	1
AC Input Voltage Range1	[187, 265] VAC
Transfer Switch Current Rating	32 A
Max Ac Input Current	32 A
DC Input Voltage Range	[36, 60] VDC
AC Output Voltage	230 VAC
AC Output Frequency	50 Hz
Short Name	4k5
Cont Power W25	4,000 W
Cont Power W40	3,700 W
Cont Power W65	3,000 W
Peak Power Rating	7,000 W
Max App Feedin Power	4,000 W
Max Efficiency	95 %
Zero Load Power	20 W
Zero Load Power AES	13 W
Zero Load Power Search	8 W
AC Input Voltage Range	[187, 265] VAC
AC Input Frequency Range	[45, 65] Hz
Charge Voltage Absorption	57.6 VDC
Charge Voltage Float	55.2 VDC
Charge Voltage Storage	52.8 VDC
Charge Algorithm	Adaptive, 4-stage
Maximum Battery Charge Current	55 A
Temperature Sensor	Included
Number Ac Outputs	2
Auxiliary Output	1
External Ac Current Sensor	50A or 100A (optional)
Programmable Relay	AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
Protections	Output short-circuit,Overload,High battery voltage,Low battery voltage,Over temperature,AC voltage on inverter output,Excessive DC ripple
Communication Port	VE.Bus
Communication Port General	1
Remote Terminal	On / Off
Computer Programming	1
Fan Assist Cooling	1
Max Humidity	95 %
Max Altitude	2,000 m
Battery Connection Terminal Type	M8 bolts
Remote Terminal Type	Screw terminal two pole
Relay Terminal	Screw terminal 3-pole
Material	Steel
Colour	Blue (RAL 5012)
Protection Category	IP21
Weight	22 kg
Height	590 mm
Width	275 mm
Depth	149 mm
Safety	EN-IEC 60335-1,EN-IEC 60335-2-29,EN-IEC 62109-1,EN-IEC 62109-2
Emission Immunity	EN 55014-1,EN 55014-2,EN-IEC 61000-3-2,EN-IEC 61000-3-3,EN-IEC 61000-6-1, EN-IEC 61000-6-2,EN-IEC 61000-6-3
Anti Islanding Standard	Please consult the certificates on our website
Ups Standard	Please consult the certificates on our website

Manufacturer Warranty
Standard Warranty:	5 years (5 years extension to 10 years for additional 10% fee - contact us for a quote)
Warranty Exceptions:	Lead acid batteries 2 years Lithium batteries 3 years
