Victron range of small Lithium batteries for small off grid set-ups that want to use Lithium batteries. Ideal for light weight solutions. 70% small and 70% lighter than Lead acid batteries.
For Victron Smart Lithium batteries it is imperative that you purchase a BMS, Battery Management System, to go with these batteries. You will kill them quickly if you don’t use one. Please ask for advice if you are not sure about which BMS is best for your application.
Lithium-iron-phosphate (LiFePO4 or LFP) is the safest of the mainstream li-ion battery types. The nominal voltage of a LFP cell is 3,2V (lead-acid: 2V/cell). A 12,8V LFP battery therefore consists of 4 cells connected in series; and a 25,6V battery consists of 8 cells connected in series.
| Victron Specifications | |
| Battery Voltage Nominal | 12.8 V |
| Battery Voltage Nominal Bucket | 12 |
| Battery Capacity Nominal | 200 Ah |
| Nominal Capacity0 | 160 Ah |
| Nominal Capacity20 | 100 Ah |
| Nominal Energy | 2,560 Wh |
| Capacity Loss | 1 % |
| Energy Loss | 1 % |
| Efficiency | 92 % |
| Chemistry | Lithium Iron Phosphate (LiFePO4 or LFP) |
| Cycle Design Life80 | 2,500 cycles |
| Cycle Design Life70 | 3,000 cycles |
| Cycle Design Life50 | 5,000 cycles |
| Max Continuous Discharge Current | 400 A |
| Rec Discharge Current | 200 A |
| End Discharge Voltage | 11.2 V |
| Internal Resistance | 0.8 m? |
| Float Charge Voltage | 13.5 V |
| Recom Max Charge Current | 100 A |
| Max Storage Time | 1 y |
| Max Humidity | 95 % |
| Bms | Male and female cable with M8 circular connector, length 50cm |
| Max Battery Per Bms | 20 (102kWh per BMS) (Up to 5 BMS-es can be paralleled) |
| Bluetooth | Yes |
| Communication Port | Bluetooth |
| Battery Terminals | M8 threaded inserts |
| Colour | Blue (RAL 5012) |
| Protection Category | IP22 |
| Mounting Orientation | The lithium battery can be mounted upright and on its side, but not with the battery terminals facing down |
| Weight | 20 kg |
| Height | 237 mm |
| Width | 321 mm |
| Depth | 152 mm |
| Safety Cells | UL 1973,IEC 62619,UL 9540A |
| Safety Battery | EN-IEC 60335-1,IEC 61427-1,IEC 62368-1 |
| E MC | EN-IEC 61000-6-3,EN 55014-1 |
| Automotive | ECE R10-6 |
| Battery | |
| Voltage | 12.8 |
| Length (mm) | 321 |
| Width (mm) | 152 |
| Total Height (mm) | 237 |
| Weight (KG) | 20 |
| Cycles DOD 50% | 5000 |
| Watt Hours | 2560 |
| Chemistry | LiFePO4 |
| Charge rate (A) | 400A Max (Recommended up to 100A) |
| Discharge rate (A) | 400A Max (Recommended up to 200A) |
| Manufacturer Warranty | |
| Standard Warranty: | 5 years (5 years extension to 10 years for additional 10% fee - contact us for a quote) |
| Warranty Exceptions: | Lead acid batteries 2 years Lithium batteries 3 years |
